The Taylor Mk2 660L Trade Waste Bin is a popular-sized bin container, and the Mk2 660 has a deceptively large capacity in a small footprint. Its slim configuration allows it to fit through a standard doorway, making it ideal for indoor storage or secure collection areas

Standard Build: Mk2 660 Litres Galvanised. Steel General Waste Recycling Bin With Danish Side Handles Internally Welded Seams, Welded On Comb Bar, EN840 compliant, Internally seam welded Hot dip galvanised body Welded comb bar, X 4 160mm Steel Centred Bolt On Castors For Easy Replacement, X 2 Foot Operated Standard Side Braked Castors X 2 Swivel Rear Castors Fitted with Black Duraflex Back Trade Lid, Lock and Base Drain Plug. Prices from: £352.00 Excluding VAT.(12 Month Warranty) Delivery Time 2-4  Working Weeks From Dispatch

Standard Build Options and Bin Finishes:
X 4 200mm Steel Centred Bolt On Castors For Easy Replacement, X 2 Foot Operated Braked Castors X 2 Swivel Rear Castors Options: Side loading DIN points, Powder coated body 12 colour options (See Colour Chart )
3 Lid types & apertures,  Duraflex Black Trade Lid,  High Dome 2 Aperture Bottle Recycling Lid,  High dome Recycling Flap Lid,:   Drain plug varieties Standard Lid Drain Plug, (Rodent Replant Drain Plug) Powder coated body colour options (See Colour Chart), Standard vinyl graphics. Custom Embossing: Hinged Drop Front Panel for Materials Storage. Hinged Drop-Back Panel Suitable for General Waste.


Images Mk2 660 For Guild Line Purposes
Galvanised Steel Shell
Seam Welded Internally
Height 1340mm
Depth 720mm
Width 1270mm
S.W.L 264Kg
Danish Side Handles
Welded Comb Bar
Standard Drain Plug
X4 Steel Centred 160mm Castors
2 Rear Swivel Castors: 2  Front Foot Operated Locking Castors
3 Duraflex Lid Options
See Drawing At the Bottom Of the Page

Available with either a Drop Front or Drop Back Panel



Mk4 660 Continental Drop Front and Drop Back containers have been created to help avoid the health and safety risks associated with handballing bagged or bulky waste, often an important requirement within retail and manufacturing environments and are easy to empty. Please note *Drop front panel bin isn’t fitted with a comb but can be fitted with weld-on DIN lift points.

All four castors are 160mm steel-centred wheels manufactured with needle bearings, grease, and rubber optimised for performance steel-centred rubber-tyred swivel castors, two of which are fitted with trailing brakes (Brakes are press to lock, press to release) and are bolted on for easy replacement. Two-foot operated, trailing braking wheels at the front with two swivel wheels at the back. (Not Welded On or Plastic Centred Castors) 200 mm Standard castors, Rubber tyres, Needle roller bearings, Trailing brakes, Pressed hubs, 3.5mm top plate, Zinc and clear passivate, 1230 Kgs static load rating, 690 Kgs dynamic load rating.

Bin Castor Options

Heavy Duty 200mm Casters: Mainly used with bins fitted with a heavy-duty base, suitable for dense waste materials (Food Waste) and also for loading waste compactors and bins fitted with External and Internal fork pockets.200 mm Heavy-duty Elastic or polyurethane tyres, Ball race bearings, leading brakes, Cast hubs, 5mm top plate, Zinc and gold passivate, 3000 Kg static load rating, 1500 kg dynamic load rating.

Non-marking castors are mainly used by Airports and Hotel lobbies, Schools, Hospitals, Offices, and Shopping Centres, which have non-marking floor Vinyl, Epoxy, and Laminate Floor covering.

Heavy Duty Power Towing Castors 2 Swivel 2 Directional Lock is designed for towing up to 4 bins and also comes standard with a heavy-duty base, including a bolt-on towing hitch and eye. 200 mm Heavy-duty High-Speed Directional Towing Castors, Elastic or polyurethane tyres, Ball race bearings, Leading brakes, Cast hubs, 5mm top plate, Zinc and gold passivate, 3000 kg static load rating, 1500 kg dynamic load rating.

Bin Towing Containers provide a safe, practical answer to all towing requirements. Any container which is to be towed should be fitted with heavy-duty Power Towing castors or two swivel castors complete with directional locks, at one end of the container, and no more than 4 containers are towed at any one time.

Please contact us on 01709 730341 if you need more information on “Towing Guidelines” or Castor Options and technical advice

Advantages of Powder Coating: Taylor Continental Bin
The container 660L can be a powder-coated option using polyester powder, which is baked and cured in a controlled oven process, providing a layer of protection against corrosion, scratches/chipping, and fading.

Taylor Mk2 Bin Trade Lid

Dimensions Duraflex Taylor - MA4927 Trade Waste 4 Wheel Bin Container lid Flat lid to fit Taylor 660 litre bins .L: 673mm x W: 1 233mm x  H: 81mm With: 7 Ribs For Optimal Strength

Taylor 660L lid is up to 4 times lighter than metal lids, thereby considerably reducing the risk of accidents to waste operatives and members of the public.
The lightweight construction of DuraFlex lids, made from high-grade UV-stabilised polyethylene, gives the same stability as heavier metal lids.
A rotomoulded DuraFlex lid can be bent or crushed several times and still revert to its original shape.

Lid Colour Option:

The 660L Trade Waste bin can be supplied without a lid if being used indoors for manufacturing and recycling applications.

Build Options
DIN points, Custom embossing, Drain plug options, External fork pockets, Different handle options, Standard and Danish, Heavy Duty Base, Central locking castors, Lid Locks,

For Further Information on the 660 Litre Trade Waste Bin: Please Phone DJE At 01709-730341 Or Via the Contact Form.

Continental Mk2 660L Standard Bin Dimensions

Maximum Payload SWL should not Exceed 268 Kgs
